Item number: 130110

Description:
Laser tube is one of the essential parts of laser equipments. Output Power: S4 rated power 100w and Maximum Power 130w. The production process of the tube is standardized, so the output power and output model are guaranteed. Long life span: We have catalyst plating in the inner wall of the laser tube. Designing lifespan is 10,000 hours.
-
Parameters:
Power output(W) : 100
Max power is 130w
Wavelength:10600nm

Length (mm) : 1400Cooling System: Water Cooling.
Triggering voltage(KV) : 22
Operating voltage(KV) : 16
Operating current (mA) : 0-27
Outer diameter(mm) : 80
Power stability: 5% or -5%
Water Cool
Package including: 1x100W laser tube.
-
You can't leave cooling water in laser tube after power off, it will freeze at Cold areas.
Optimum working water temperature is 5-40 degrees.
working lifetime up to 10000 hours (According to the water temperature, continuous workload, the use of laser intensity and other aspects to determine)
The Laser tube after generally work 3-4 hours should to pause for about 30 minutes.
Low power can extend the life of the tube.
-
