Item number: 160358
-
The desktop automatic filling and packaging machine can automatically complete tasks such as metering, filling, and mixing. It is suitable for packing granule materials that are easy to flow or have poor fluidity, such as feed, Rice noodles, white sugar, coffee, monosodium glutamate and granule additives, etc.

Note:
1.The desktop filling machine is not equipped with weighing mode (the display screen template shares a set of templates, although there is an option for weighing mode, it is not actually available on this machine.)

2.All weighing related functions in the machine cannot be implemented, and panel programming is a common set.

Product parameters
Voltage: 110V/60Hz
Power: 1.6 KW
Material: The surface is stainless steel
Measurement method: weighing feedback tracking spiral rotation filling type
Packaging weight: 10-200g (If customers want to achieve different packaging ranges, they need to change the screw accessories and purchase them themselves.)
Packaging accuracy: packaging weight ≤ 100g, deviation ≤ ± 0.5-1g
Product size(Exterior sizes): 23.6"x22.83"x55.9" (60x58x142cm)(The highest height is adjustable)
Packaging weight ≥ 100g, deviation ≤ ± 0.5-1%
Packaging speed: 15-30bags/min
Bin volume: 15L

Feature:
There are three filling modes:

Automatic mode (after being turned on, the next filling will continue after the completion of one filling)

Fine adjustment mode (slowly increase the weight, such as 200 grams. When filling to 190 grams, use fine adjustment, and the material will be slowly filled bit by bit)

Quantitative mode (after setting the filling weight, each filling weight will be equal)

Note:The desktop filling machine is not equipped with weighing mode (the display screen template shares a set of templates, although there is an option for weighing mode, it is not actually available on this machine.)

There are three options for mixing modes:

Mixing normally open: The mixing leaves in the hopper will continuously stir without stopping, including when not filling

Mixing followed by filling: the mixing function will only be automatically started during filling

Mixing normally off: turn off the mixing function

Note:
To use automatic mode, it is necessary to connect the supporting equipment conveyor belt, which cannot be achieved by a separate filling machine.

This machine adopts high quality buckle connection, convenient disassembly and replacement.

Touch screen man-machine interface: stable operation, anti-interference, convenient and intuitive operation.

This machine is equipped with an adjustable handwheel. Turning the handwheel clockwise can raise the filling section to meet the needs of customers at different heights.

This machine is equipped with a visual window, which allows for a more intuitive view of the material unloading process and enables timely addition of materials.

This machine is equipped with high-quality motors, with stable performance and low noise.

The machine is equipped with an enlarged feed inlet for easy filling of materials.

The machine is equipped with a chain plate conveyor belt, which is more wear-resistant and can be used in conjunction with the conveyor belt.

The machine is equipped with an emergency stop switch, which can stop all work with one click for greater safety.

Product safety precautions:
To ensure safe production, please carefully read the following precautions:

1. Use a power supply that meets the requirements of this device, and ensure that the voltage is stable.

2.After turning off the power switch, there is still voltage in the electrical control circuit of this machine. When repairing the control circuit, be sure to unplug the power cord.

3. Do not put your hands into the mixing bucket while working, and pay attention to personal safety.

3.When there is a problem with the machine, directly press the emergency stop button to stop all work.

Usage steps:
Step 1, add powder material.
Step 2,Turn on the power, confirm the voltage and connect the machine to 110V power supply.
Step 3, rotate the emergency stop switch, and then set the parameters on the operation panel.
Step 4, prepare the container for filling, start the machine for filling.
Step 5, turn off the power in time after the filling is finished.

Advantages:
1. The entire machine is made of stainless steel and can be used for packaging various products.
2. Touch screen man-machine interface: stable operation, anti-interference, convenient and intuitive operation.
3. The filling adopts a stepping motor moving screw, which has the advantages of accurate positioning, high accuracy, fast speed, large torque, long service life, adjustable rotational speed, and good stability.
4. Mixing adopts high-quality motor: low noise, long service life.
5. High quality material box, clear movement and static of materials at a glance, and no dust leakage.
6. The replacement of screw accessories can adapt to a variety of materials, from superfine to large particles. (Our matching screw can be used for 10-200g.This machine is equipped with a 26MM caliber discharge screw as standard. If customers have other requirements, they can consult us to purchase separately.)

Note: Due to the different production batches, the appearance and color of the product is slightly different, the above two styles of machines shipped randomly.

Item Included: 160358
1*Automatic tabletop filling machine
